Time Series Analysis of Satellite Data

When does vegetation green-up each spring? Is there a long-term trend in productivity? How does drought affect growing seasons? Time series analysis of satellite data decomposes observations into trend, seasonality, and noise, enabling phenology extraction, anomaly detection, and climate change assessment. This model derives harmonic analysis, implements smoothing filters, and extracts phenological metrics.

Prerequisites: time series decomposition, fourier analysis, trend detection, smoothing

27 Feb 2026 Updated 12 Mar 2026 14 min read

1. The Question

How has the growing season changed over the past 20 years?

Time series analysis examines sequences of observations through time:

Satellite time series:

MODIS: 500m, 16-day composites, 2000-present
Landsat: 30m, 16-day revisit, 1984-present
Sentinel-2: 10m, 5-day revisit, 2015-present

Applications:

Phenology: Timing of green-up, peak, senescence
Productivity trends: Is vegetation increasing or decreasing?
Drought detection: NDVI anomalies below normal
Crop monitoring: Within-season growth patterns
Climate change: Lengthening/shortening growing seasons
Forest health: Detecting gradual decline vs. abrupt disturbance

The mathematical question: Given a noisy time series of NDVI values, how do we separate:

Trend: Long-term change
Seasonality: Repeating annual cycle
Noise: Random variation and clouds

2. The Conceptual Model

Time Series Components

Additive model:

\[y(t) = T(t) + S(t) + \varepsilon(t)\]

Where:

$y(t)$ = observed value at time $t$
$T(t)$ = trend component
$S(t)$ = seasonal component
$\varepsilon(t)$ = noise/residual

Example - NDVI time series:

Trend: Gradual greening (+0.001 NDVI/year)
Seasonal: Spring green-up, summer peak, autumn senescence
Noise: Clouds, atmospheric effects, sensor variations

Phenological Metrics

Key dates in annual cycle:

Start of Season (SOS): When NDVI crosses threshold (spring green-up)
Peak of Season (POS): Maximum NDVI (summer)
End of Season (EOS): When NDVI falls below threshold (senescence)
Growing Season Length (GSL): EOS - SOS

Amplitude: Difference between peak and minimum NDVI

Integrated NDVI: Area under curve (proportional to productivity)

Harmonic Analysis

Model seasonal cycle with sine/cosine:

\[S(t) = A \sin(2\pi t / P + \phi)\]

Where:

$A$ = amplitude
$P$ = period (365 days)
$\phi$ = phase (timing of peak)

Multiple harmonics capture complex seasonal patterns:

\[S(t) = \sum_{k=1}^{n} \left[a_k \cos(2\pi k t / P) + b_k \sin(2\pi k t / P)\right]\]

k=1: Annual cycle
k=2: Bi-annual (two peaks per year)
k=3: Tri-annual, etc.

3. Building the Mathematical Model

Moving Average Smoothing

Simple moving average (window size $w$):

\[\hat{y}_t = \frac{1}{w} \sum_{i=t-w/2}^{t+w/2} y_i\]

Reduces noise but blurs edges.

Typical: $w = 3$ (adjacent observations)

Savitzky-Golay Filter

Fits polynomial to local window, evaluates at center.

Preserves peaks better than moving average.

Algorithm: For each point, fit polynomial of degree $d$ to $w$ neighbors, use fitted value.

Typical: $w = 5$, $d = 2$ (quadratic)

Trend Extraction

Linear trend:

\[T(t) = \beta_0 + \beta_1 t\]

Fit via least squares:

\[\beta_1 = \frac{\sum (t_i - \bar{t})(y_i - \bar{y})}{\sum (t_i - \bar{t})^2}\] \[\beta_0 = \bar{y} - \beta_1 \bar{t}\]

Interpretation:

$\beta_1 > 0$: Increasing trend (greening)
$\beta_1 < 0$: Decreasing trend (browning)
$\beta_1 = 0$: No trend

Mann-Kendall test: Non-parametric trend significance test.

Harmonic Regression

Fit annual cycle:

\[y(t) = \beta_0 + a_1\cos(\omega t) + b_1\sin(\omega t) + \varepsilon(t)\]

Where $\omega = 2\pi / 365$ (radians/day).

Amplitude:

\[A = \sqrt{a_1^2 + b_1^2}\]

Phase (peak timing):

\[\phi = \arctan(b_1 / a_1)\]

Day of year for peak:

\[\text{DOY}_{\text{peak}} = \phi \times \frac{365}{2\pi}\]

Add trend:

\[y(t) = \beta_0 + \beta_1 t + a_1\cos(\omega t) + b_1\sin(\omega t)\]

Phenology Extraction

Threshold method:

Start of Season: First day when $\text{NDVI} > T_{\text{green}}$

End of Season: Last day when $\text{NDVI} > T_{\text{green}}$

Typical threshold: $T_{\text{green}} = 0.3$ or $T_{\text{green}} = \text{NDVI}{\min} + 0.2(\text{NDVI}{\max} - \text{NDVI}_{\min})$

Derivative method:

SOS: Maximum rate of increase

\[\frac{d\text{NDVI}}{dt} = \max\]

EOS: Maximum rate of decrease

\[\frac{d\text{NDVI}}{dt} = \min\]

4. Worked Example by Hand

Problem: Extract phenology from simplified annual NDVI time series.

Monthly NDVI values (2023):

Month	DOY	NDVI
Jan	15	0.25
Feb	45	0.28
Mar	75	0.35
Apr	105	0.50
May	135	0.68
Jun	165	0.75
Jul	195	0.72
Aug	225	0.65
Sep	255	0.50
Oct	285	0.35
Nov	315	0.28
Dec	345	0.25

Find: SOS, POS, EOS, GSL using threshold $T = 0.4$

Solution

Step 1: Find Start of Season

First month when NDVI > 0.4:

Jan: 0.25 < 0.4
Feb: 0.28 < 0.4
Mar: 0.35 < 0.4
Apr: 0.50 > 0.4 ✓

SOS ≈ DOY 105 (mid-April)

Step 2: Find Peak of Season

Maximum NDVI:

Max = 0.75 in June

POS = DOY 165 (mid-June)

Step 3: Find End of Season

Last month when NDVI > 0.4:

Sep: 0.50 > 0.4 ✓
Oct: 0.35 < 0.4

EOS ≈ DOY 255 (mid-September)

Step 4: Growing Season Length

\[\text{GSL} = \text{EOS} - \text{SOS} = 255 - 105 = 150 \text{ days}\]

Step 5: Integrated NDVI (productivity)

Trapezoidal integration (approximate area under curve):

\[\int \text{NDVI} \, dt \approx \sum_{i=1}^{n-1} \frac{\text{NDVI}_i + \text{NDVI}_{i+1}}{2} \times \Delta t\] \[\approx \frac{0.25+0.28}{2}\times30 + \frac{0.28+0.35}{2}\times30 + \cdots\] \[\approx 30 \times (0.265 + 0.315 + 0.425 + 0.590 + 0.715 + 0.735 + 0.685 + 0.575 + 0.425 + 0.315 + 0.265)\] \[\approx 30 \times 5.31 = 159.3 \text{ NDVI-days}\]

Summary:

SOS: DOY 105
POS: DOY 165
EOS: DOY 255
GSL: 150 days
Integrated NDVI: ~159 (productivity proxy)

5. Computational Implementation

Below is an interactive time series analyzer.

Location type: Show components: Trend Seasonal Smoothed Phenology threshold: 0.40

Start of Season: --

Peak of Season: --

End of Season: --

Growing Season Length: -- days

Trend: -- NDVI/year

Try this:

Temperate forest: Strong seasonal cycle, single peak
Grassland: Similar but smaller amplitude
Tropical evergreen: Minimal seasonality (always green)
Cropland: Double-crop pattern (two peaks per year!)
Show trend: Red dashed line (long-term change)
Show seasonal: Green line (trend + seasonality)
Show smoothed: Blue line (noise reduced)
Adjust threshold: Changes SOS/EOS detection
Phenology markers: Green (SOS), Purple (POS), Orange (EOS)

Key insight: Time series decomposition separates long-term trends from seasonal cycles, enabling climate change detection and phenology monitoring!

6. Interpretation

Climate Change Signals

Global greening trend:

NDVI increased ~0.001-0.002/year (1982-2015)
Reasons: CO₂ fertilization, warmer temperatures, longer growing seasons
Arctic: Strongest greening (shrub expansion)

Growing season extension:

SOS earlier (1-2 weeks in 40 years)
EOS later (1 week)
Net: +10-20 days GSL in northern latitudes

Drought Monitoring

NDVI anomaly:

\[A(t) = \text{NDVI}(t) - \text{NDVI}_{\text{climatology}}(t)\]

Where climatology = long-term average for that time of year.

Negative anomaly = drought stress

Example: 2012 US drought

NDVI anomaly < -0.15 across Corn Belt
Early warning of crop failure

Agricultural Phenology

Crop calendars from satellites:

SOS = planting date
POS = peak vegetative growth
EOS = harvest date

Applications:

Yield forecasting (early prediction)
Insurance claims (verify timing)
Double-cropping detection

7. What Could Go Wrong?

Cloud Contamination

Clouds reduce NDVI (appear as low values).

Spurious phenology:

Cloudy spring → delayed SOS (false)
Need cloud masking

Solutions:

Composite images (maximum NDVI in period)
Cloud screening (quality flags)
Gap-filling interpolation

Missing Data

Landsat: 16-day repeat but clouds may leave gaps.

Irregular time series → difficult to analyze.

Solutions:

Interpolation (linear, spline)
Harmonic fitting (smooth through gaps)
Data fusion (combine Landsat + Sentinel)

Sensor Drift

Long-term sensors (AVHRR, MODIS) degrade over time.

Calibration drift → false trend.

Solution:

Cross-calibration between sensors
Atmospheric correction updates
Use surface reflectance products

Mixed Land Cover

Pixel contains multiple types (e.g., 50% forest, 50% grass).

Phenology represents blend → hard to interpret.

Solution:

Use finer resolution
Classify first, then analyze per class
Sub-pixel unmixing

8. Extension: TIMESAT

Software package for time series processing.

Functions:

Gap-filling (interpolation)
Smoothing (Savitzky-Golay, asymmetric Gaussian)
Phenology extraction (multiple methods)
Visualization

Three fitting methods:

Asymmetric Gaussian: Separate rise/fall curves
Double logistic: S-curves for green-up/senescence
Savitzky-Golay filter: Polynomial smoothing

Outputs:

Start/end of season
Length of season
Base/peak/amplitude
Small/large integrals (productivity metrics)

Widely used in operational phenology monitoring.

9. Math Refresher: Fourier Series

Periodic Function Decomposition

Any periodic function with period $P$ can be represented as:

\[f(t) = a_0 + \sum_{k=1}^{\infty} \left[a_k\cos(k\omega t) + b_k\sin(k\omega t)\right]\]

Where $\omega = 2\pi / P$ (fundamental frequency).

Coefficients:

\[a_0 = \frac{1}{P}\int_0^P f(t)\,dt\] \[a_k = \frac{2}{P}\int_0^P f(t)\cos(k\omega t)\,dt\] \[b_k = \frac{2}{P}\int_0^P f(t)\sin(k\omega t)\,dt\]

Application to NDVI

For annual cycle ($P = 365$ days):

First harmonic (k=1): Annual component

Second harmonic (k=2): Bi-annual (captures double-cropping)

Typically: 1-3 harmonics sufficient for most vegetation.

Amplitude of harmonic k:

\[A_k = \sqrt{a_k^2 + b_k^2}\]

Phase (timing of peak):

\[\phi_k = \arctan(b_k / a_k)\]

Summary

Time series analysis decomposes observations into trend, seasonality, and noise
Phenological metrics: Start of season (SOS), peak (POS), end (EOS), growing season length (GSL)
Harmonic analysis: Models seasonality using sine/cosine functions
Trend extraction: Linear regression to detect long-term change
Smoothing filters: Moving average or Savitzky-Golay to reduce noise
Applications: Climate change detection, drought monitoring, crop calendars, forest health
Challenges: Clouds, missing data, sensor drift, mixed pixels
TIMESAT: Standard software for operational phenology extraction
Global observations: Growing season lengthening, Arctic greening, NDVI anomalies indicate drought
Critical for understanding vegetation dynamics and climate change impacts
