Raster Resampling and Interpolation

What happens when you zoom in on satellite imagery? How do you convert a 30m DEM to 10m resolution? Resampling changes raster resolution, while interpolation estimates values at unmeasured locations. This model derives nearest neighbor, bilinear, and bicubic methods, showing when each is appropriate.

Prerequisites: interpolation, nearest neighbor, bilinear, bicubic, weighted averaging

27 Feb 2026 Updated 12 Mar 2026 14 min read

1. The Question

How do you convert a 30-meter resolution satellite image to 10-meter resolution?

Resampling changes the grid spacing of raster data:

Upsampling (zoom in): Fewer pixels → more pixels (decrease cell size)
Downsampling (zoom out): More pixels → fewer pixels (increase cell size)
Reprojection: Change coordinate system (requires resampling)

Interpolation estimates values between measured points:

DEM creation: Points from LiDAR → continuous elevation surface
Climate mapping: Weather stations → temperature grid
Missing data: Cloud gaps in satellite imagery → fill with neighbors

The mathematical question: Given values at known grid positions, how do we estimate values at new positions?

Trade-offs:

Speed vs. quality: Fast methods produce blocky results
Smoothness vs. fidelity: Smooth methods may blur sharp features
Artifacts: Poor methods create visual or analytical problems

2. The Conceptual Model

The Resampling Problem

Input raster: Grid with cell size $\Delta x_1$, values $z_{i,j}$

Output raster: New grid with cell size $\Delta x_2$

Challenge: Output pixel centers don’t align with input pixels.

Example: Convert 30m DEM to 10m DEM

Input: 100×100 grid (30m cells)
Output: 300×300 grid (10m cells)
Must estimate elevation at 90,000 new positions from 10,000 known values

Three Classical Methods

1. Nearest Neighbor

Use value from closest input pixel.

\[z_{\text{new}}(x, y) = z_{i,j} \text{ where } (i,j) = \text{nearest to } (x,y)\]

Pros: Fast, preserves original values (good for categorical data)
Cons: Blocky appearance, discontinuous

2. Bilinear Interpolation

Weighted average of 4 nearest pixels.

\[z(x, y) = (1-u)(1-v)z_{0,0} + u(1-v)z_{1,0} + (1-u)vz_{0,1} + uvz_{1,1}\]

Where $u, v$ are fractional positions within cell.

Pros: Smooth, continuous
Cons: Blurs edges, creates new values not in original data

3. Bicubic Interpolation

Weighted average of 16 nearest pixels using cubic polynomials.

Pros: Very smooth, preserves gradients
Cons: Slower, can overshoot (create values outside original range)

3. Building the Mathematical Model

Grid Coordinates

Input pixel $(i, j)$ with value $z_{i,j}$

Pixel center in world coordinates:

$x = x_0 + i \cdot \Delta x$ $y = y_0 - j \cdot \Delta y$

(Note: $y$ decreases with row index—image convention)

Query point $(x_q, y_q)$: Where do we want to estimate $z$?

Find containing cell:

$i_q = \lfloor (x_q - x_0) / \Delta x \rfloor$ $j_q = \lfloor (y_q - y_0) / \Delta y \rfloor$

Fractional position within cell:

$u = \frac{x_q - x_0}{\Delta x} - i_q$ $v = \frac{y_q - y_0}{\Delta y} - j_q$

Where $0 \leq u, v < 1$.

Nearest Neighbor

Algorithm:

i_nearest = round((xq - x0) / dx)
j_nearest = round((yq - y0) / dy)
z_interp = z[i_nearest, j_nearest]

Equivalent: Round $u, v$ to 0 or 1.

Decision boundary: Each output pixel assigned to nearest input pixel.

Result: Piecewise constant (stair-step appearance).

Bilinear Interpolation

Four corners of cell:

$z_{0,0} = z[i_q, j_q]$ (bottom-left)
$z_{1,0} = z[i_q+1, j_q]$ (bottom-right)
$z_{0,1} = z[i_q, j_q+1]$ (top-left)
$z_{1,1} = z[i_q+1, j_q+1]$ (top-right)

Linear interpolation in x:

$z_0 = (1-u)z_{0,0} + u z_{1,0}$ (bottom edge) $z_1 = (1-u)z_{0,1} + u z_{1,1}$ (top edge)

Linear interpolation in y:

\[z(u, v) = (1-v)z_0 + v z_1\]

Expanded form:

\[z = (1-u)(1-v)z_{0,0} + u(1-v)z_{1,0} + (1-u)v z_{0,1} + uv z_{1,1}\]

Weights sum to 1:

$(1-u)(1-v) + u(1-v) + (1-u)v + uv = 1$ ✓

Properties:

Continuous (no jumps)
$C^0$ continuous (values match, derivatives don’t)
Exact at grid points: $z(0,0) = z_{0,0}$, etc.

Bicubic Interpolation

Uses 16 pixels (4×4 neighborhood centered on query point).

Cubic convolution kernel:

\[w(x) = \begin{cases} (a+2)|x|^3 - (a+3)|x|^2 + 1 & \text{if } |x| \leq 1 \\ a|x|^3 - 5a|x|^2 + 8a|x| - 4a & \text{if } 1 < |x| < 2 \\ 0 & \text{if } |x| \geq 2 \end{cases}\]

Where $a = -0.5$ (standard choice) or $a = -0.75$ (sharper).

Interpolation:

\[z(u, v) = \sum_{m=0}^{3} \sum_{n=0}^{3} z_{m-1, n-1} \cdot w(m - u) \cdot w(n - v)\]

Properties:

$C^1$ continuous (smooth derivatives)
Preserves local shape better than bilinear
Can overshoot (produce values < min or > max of neighbors)

4. Worked Example by Hand

Problem: Resample this 2×2 elevation grid to find elevation at $(1.3, 0.7)$ using bilinear interpolation.

Input grid (1m cells):

       x=0   x=1   x=2
y=0    100   110
y=1    105   120

Grid origin at $(0, 0)$, cell size = 1m.

Query point: $(x_q, y_q) = (1.3, 0.7)$

Solution

Step 1: Find containing cell

$i_q = \lfloor 1.3 / 1 \rfloor = 1$ $j_q = \lfloor 0.7 / 1 \rfloor = 0$

Cell corners at: $(1,0)$, $(2,0)$, $(1,1)$, $(2,1)$

Step 2: Fractional position

$u = 1.3 - 1 = 0.3$ $v = 0.7 - 0 = 0.7$

Step 3: Get corner values

$z_{0,0} = z[1,0] = 110$ (bottom-left of cell)
$z_{1,0} = z[2,0] = ?$ (missing—assume 115 for example)
$z_{0,1} = z[1,1] = 120$ (top-left)
$z_{1,1} = z[2,1] = ?$ (assume 125)

Actually, our grid only goes to $x=1$. Let me recalculate with correct bounds.

Corrected: Query $(1.3, 0.7)$ is outside grid. Let’s use $(0.3, 0.7)$ instead.

Step 1 (corrected):

$i_q = \lfloor 0.3 / 1 \rfloor = 0$ $j_q = \lfloor 0.7 / 1 \rfloor = 0$

Step 2:

$u = 0.3 - 0 = 0.3$ $v = 0.7 - 0 = 0.7$

Step 3: Corner values

$z_{0,0} = z[0,0] = 100$
$z_{1,0} = z[1,0] = 110$
$z_{0,1} = z[0,1] = 105$
$z_{1,1} = z[1,1] = 120$

Step 4: Bilinear formula

$z = (1-0.3)(1-0.7) \cdot 100 + (0.3)(1-0.7) \cdot 110$ $\quad + (1-0.3)(0.7) \cdot 105 + (0.3)(0.7) \cdot 120$

$= 0.7 \times 0.3 \times 100 + 0.3 \times 0.3 \times 110$ $\quad + 0.7 \times 0.7 \times 105 + 0.3 \times 0.7 \times 120$

\[= 21 + 9.9 + 51.45 + 25.2 = 107.55 \text{ m}\]

Verification:

Nearest to $(0,1)$ at 105m (weight 0.49)
Also weighted toward 110 and 120
Result 107.55 is reasonable weighted average

5. Computational Implementation

Below is an interactive resampling demonstration.

Method: Output resolution: 10× Show input grid:

Input cells: 5×5 = 25

Output cells: --

Sampling ratio: --×

Try this:

Nearest neighbor: Blocky, stair-step appearance (preserves exact values)
Bilinear: Smooth, continuous (but blurs the peak)
Bicubic: Very smooth (may overshoot slightly)
Increase resolution: More output pixels reveal interpolation differences
Color scale: Blue = low elevation, Red = high elevation
Notice: Nearest neighbor preserves sharp gradients, bilinear smooths them

Key insight: Method choice depends on data type—categorical (land cover) needs nearest neighbor, continuous (elevation) benefits from bilinear/bicubic.

6. Interpretation

When to Use Each Method

Nearest Neighbor:

Categorical data: Land cover, soil types, zoning codes
Preserving exact values: Don’t want interpolated values (e.g., “class 2.3”)
Speed critical: Fastest method
Example: Reproject land cover map—don’t create new land cover classes

Bilinear:

Continuous data: Elevation, temperature, NDVI
General purpose: Good balance of speed and quality
Moderate smoothing acceptable: Slight blur is OK
Example: Resize satellite imagery for display

Bicubic:

High-quality visualization: Print maps, publications
Preserving gradients: Slope/aspect calculation from DEM
Smooth interpolation needed: Climate surfaces, bathymetry
Example: Upsample DEM for detailed terrain visualization

Aliasing in Downsampling

Problem: Downsampling without filtering causes aliasing (high-frequency artifacts).

Example: 100m DEM → 1000m DEM by sampling every 10th pixel

Misses peaks/valleys between sampled points
Creates artificial patterns

Solution: Average all input pixels that fall within output pixel (anti-aliasing filter).

For each output pixel:
    Find all input pixels within its extent
    z_output = mean(z_input)

This is area-weighted averaging, not interpolation.

Reprojection

Changing coordinate systems requires resampling:

1. Create output grid in new projection
2. For each output pixel:
    a. Transform pixel center to input projection
    b. Interpolate value from input grid
    c. Assign to output pixel

Challenge: Output pixel may correspond to irregular shape in input space.

Common practice: Use bilinear for most data, nearest neighbor for categorical.

7. What Could Go Wrong?

Overshoot in Bicubic

Bicubic can create values outside input range.

Example:

Input range: [0, 255] (8-bit image)
Bicubic output: Values like -5 or 270

Problem: Invalid for physical quantities (negative reflectance, temperatures > known max)

Solution: Clamp output to valid range: value = max(min_valid, min(max_valid, value))

Edge Effects

Near grid boundaries: Insufficient neighbors for bilinear/bicubic.

Options:

Fallback to nearest neighbor at edges
Pad with replicated edge values
Assume zeros beyond boundary
Reflect boundary (mirror)

Choice depends on data semantics.

Assuming Regular Grid

Many interpolation methods assume:

Rectangular grid
Uniform spacing
Aligned with axes

Real data may be:

Irregular point clouds (LiDAR)
Rotated grids
Variable resolution

Solution: Use scattered data interpolation (IDW, kriging) or triangulation.

Excessive Smoothing

Bilinear/bicubic blur sharp features.

Problem for:

Coastlines (land/water boundary)
Faults (abrupt elevation change)
Roads (linear features)

Solution:

Use nearest neighbor for boundaries
Edge-preserving filters
Or accept smoothing as necessary artifact

8. Extension: Advanced Interpolation

Inverse Distance Weighting (IDW)

For irregular point data:

\[z(x, y) = \frac{\sum_i w_i z_i}{\sum_i w_i}\]

Where:

\[w_i = \frac{1}{d_i^p}\]

$d_i$ = distance from $(x,y)$ to point $i$
$p$ = power parameter (typically 2)

Nearby points have more influence (high weight).

Kriging

Geostatistical interpolation using spatial covariance.

Steps:

Fit variogram (model of spatial correlation vs. distance)
Solve system of equations for weights
Compute weighted sum (optimal in least-squares sense)

Advantage: Provides uncertainty estimates.

Disadvantage: Computationally expensive, requires expertise.

Thin Plate Splines

Minimizes bending energy (creates smoothest surface).

Used for:

Climate data interpolation
Surface fitting with constraints
Morphing between shapes

Disadvantage: Global method (slow for large datasets).

9. Math Refresher: Linear Interpolation

1D Case

Points: $(x_0, y_0)$ and $(x_1, y_1)$

Interpolate at $x$:

\[y = y_0 + \frac{x - x_0}{x_1 - x_0}(y_1 - y_0)\]

Equivalent form:

\[y = (1 - t) y_0 + t y_1\]

Where $t = \frac{x - x_0}{x_1 - x_0}$ is normalized position.

Properties:

Linear in $x$
Exact at endpoints: $y(x_0) = y_0$, $y(x_1) = y_1$
$t = 0$ → $y = y_0$; $t = 1$ → $y = y_1$

2D Extension (Bilinear)

Apply linear interpolation twice:

Interpolate along x at $y_0$: get $f(x, y_0)$
Interpolate along x at $y_1$: get $f(x, y_1)$
Interpolate between these along y: get $f(x, y)$

Result: Bilinear = product of two linear interpolations.

Not the same as 2D linear (plane through 3 points)—bilinear is a hyperbolic paraboloid (saddle shape).

Summary

Resampling changes grid resolution (upsampling or downsampling)
Interpolation estimates values at new positions from known values
Nearest neighbor: Fast, preserves values, blocky (use for categorical data)
Bilinear: Smooth, continuous, general-purpose (use for continuous data)
Bicubic: Very smooth, preserves gradients, can overshoot (use for high-quality)
Downsampling needs filtering to avoid aliasing (average, don’t just sample)
Reprojection requires resampling (transform coordinates, then interpolate)
Challenges: Edge effects, overshoot, excessive smoothing
Advanced methods: IDW, kriging, splines for irregular data
Interpolation is weighted averaging where weights depend on distance/position
