Polygon Overlay and Clipping

What area is both forest AND protected? What land is zoned residential OR commercial? Overlay operations—intersection, union, difference—combine spatial datasets to answer "where" questions. This model derives the Weiler-Atherton clipping algorithm and implements polygon boolean operations from first principles.

Prerequisites: set operations, boolean algebra, line intersection, polygon clipping

27 Feb 2026 Updated 12 Mar 2026 15 min read

1. The Question

Which parcels are both inside the floodplain AND zoned for development?

Overlay operations combine two spatial datasets using set operations:

Intersection (AND): Areas in both datasets

Forest ∩ Protected areas = Protected forest
Floodplain ∩ Development zones = Flood-risk development areas
Species habitat ∩ Private land = Conservation priority areas

Union (OR): Areas in either dataset

Parks ∪ Preserves = All protected areas
Urban ∪ Agricultural = Developed land
Fire risk zones ∪ Drought zones = Combined hazard areas

Difference (NOT): Areas in first but not second

Total land \ Water bodies = Land area only
Proposed development \ Wetlands = Developable area
National forest \ Wilderness areas = Multiple-use forest

The mathematical question: How do we compute the intersection, union, or difference of two polygons?

2. The Conceptual Model

Set Operations on Polygons

Polygons as sets of points:

Polygon $A = {(x,y) : \text{point inside polygon A}}$

Boolean operations:

\[A \cap B = \{(x,y) : (x,y) \in A \text{ AND } (x,y) \in B\}\] \[A \cup B = \{(x,y) : (x,y) \in A \text{ OR } (x,y) \in B\}\] \[A \setminus B = \{(x,y) : (x,y) \in A \text{ AND } (x,y) \notin B\}\]

Result: New polygon(s) representing the combined area.

The Clipping Problem

Special case: Clip polygon $A$ to window $B$ (intersection).

Examples:

Clip state boundaries to study area rectangle
Clip satellite image to county boundary
Clip parcels to watershed boundary

Challenge: Find vertices of resulting polygon.

Required pieces:

Vertices from $A$ inside $B$
Vertices from $B$ inside $A$
Edge-edge intersection points
Correct traversal order

3. Building the Mathematical Model

Line Segment Intersection

Foundation: Must detect where polygon edges cross.

Segments: $P_1P_2$ and $Q_1Q_2$

Parametric form:

$P(s) = P_1 + s(P_2 - P_1), \quad s \in [0,1]$ $Q(t) = Q_1 + t(Q_2 - Q_1), \quad t \in [0,1]$

Intersection: Find $s, t$ where $P(s) = Q(t)$:

\[P_1 + s(P_2 - P_1) = Q_1 + t(Q_2 - Q_1)\]

Solve 2×2 system:

Let $\mathbf{d}_P = P_2 - P_1$, $\mathbf{d}_Q = Q_2 - Q_1$, $\mathbf{r} = P_1 - Q_1$

\[s \mathbf{d}_P - t \mathbf{d}_Q = -\mathbf{r}\]

Matrix form:

\[\begin{pmatrix} d_{Px} & -d_{Qx} \\ d_{Py} & -d_{Qy} \end{pmatrix} \begin{pmatrix} s \\ t \end{pmatrix} = \begin{pmatrix} -r_x \\ -r_y \end{pmatrix}\]

Determinant:

\[D = d_{Px} \cdot d_{Qy} - d_{Py} \cdot d_{Qx}\]

If $D = 0$: segments are parallel (no intersection or infinite intersections)

Solution:

\[s = \frac{(Q_1 - P_1) \times (Q_2 - Q_1)}{(P_2 - P_1) \times (Q_2 - Q_1)}\] \[t = \frac{(Q_1 - P_1) \times (P_2 - P_1)}{(P_2 - P_1) \times (Q_2 - Q_1)}\]

Where $\times$ is 2D cross product: $(x_1, y_1) \times (x_2, y_2) = x_1 y_2 - y_1 x_2$

Intersection exists if: $0 \leq s \leq 1$ AND $0 \leq t \leq 1$

Intersection point:

\[I = P_1 + s(P_2 - P_1)\]

Weiler-Atherton Algorithm

Input: Two simple polygons $A$ (subject) and $B$ (clip)

Output: Intersection polygon $A \cap B$

Algorithm steps:

1. Find all edge intersections

For each edge of $A$ and each edge of $B$:

Test for intersection
Record intersection points
Label as “entering” or “leaving”

Entering: Edge goes from outside $B$ to inside $B$
Leaving: Edge goes from inside $B$ to outside $B$

2. Build vertex list

For polygon $A$:

Original vertices
Intersection points (inserted in traversal order)
Mark each vertex: inside/outside $B$

For polygon $B$:

Original vertices
Intersection points
Mark each vertex: inside/outside $A$

3. Trace boundary

Start at an intersection point marked “entering”:

Follow $A$ edges while inside $B$
At “leaving” intersection, switch to following $B$ edges
At next “entering” intersection, switch back to $A$
Continue until returning to start

Output: Sequence of vertices forming intersection polygon.

Union Algorithm

Union = all area covered by either polygon

Weiler-Atherton modification:

Instead of following edges “inside” clip polygon, follow edges “outside”:

Start at “leaving” intersection
Follow edges while outside the other polygon
Switch at intersections

Multiple components: Union may produce multiple disconnected polygons (if originals don’t overlap).

Difference Algorithm

Difference $A \setminus B$ = area in $A$ but not in $B$

Implementation:

Follow $A$ edges normally, but when inside $B$:

Switch to following $B$ boundary in reverse direction
This “cuts out” the $B$ region

Equivalent: $A \setminus B = A \cap \overline{B}$ (intersection with complement)

4. Worked Example by Hand

Problem: Find intersection of:

Rectangle $A$: corners at $(0,0)$, $(4,0)$, $(4,3)$, $(0,3)$
Rectangle $B$: corners at $(2,1)$, $(6,1)$, $(6,4)$, $(2,4)$

Solution

Step 1: Find edge intersections

Edges of $A$:

Bottom: $(0,0)$ to $(4,0)$
Right: $(4,0)$ to $(4,3)$
Top: $(4,3)$ to $(0,3)$
Left: $(0,3)$ to $(0,0)$

Edges of $B$:

Bottom: $(2,1)$ to $(6,1)$
Right: $(6,1)$ to $(6,4)$
Top: $(6,4)$ to $(2,4)$
Left: $(2,4)$ to $(2,1)$

Test all pairs:

$A$ right $(4,0) \to (4,3)$ intersects $B$ bottom $(2,1) \to (6,1)$:

At point $(4,1)$ ✓

$A$ right $(4,0) \to (4,3)$ intersects $B$ top $(6,4) \to (2,4)$:

No (doesn’t reach $y=4$)

$A$ top $(4,3) \to (0,3)$ intersects $B$ left $(2,4) \to (2,1)$:

At point $(2,3)$ ✓

Intersections found: $(4,1)$ and $(2,3)$

Step 2: Classify intersections

At $(4,1)$:

Edge $(4,0) \to (4,3)$ goes from outside $B$ to inside $B$ → Entering

At $(2,3)$:

Edge $(4,3) \to (0,3)$ goes from inside $B$ to outside $B$ → Leaving

Step 3: Build intersection polygon

Start at entering intersection $(4,1)$:

Follow $A$ edge to $(4,3)$
Continue to leaving intersection $(2,3)$
Switch to $B$ edges
Follow $B$ bottom from $(2,1)$ to entering intersection $(4,1)$

Intersection polygon: $(4,1) \to (4,3) \to (2,3) \to (2,1) \to (4,1)$

Result: Rectangle with corners $(2,1)$, $(4,1)$, $(4,3)$, $(2,3)$

Area: $(4-2) \times (3-1) = 2 \times 2 = 4$ square units ✓

5. Computational Implementation

Below is an interactive polygon overlay demonstration.

Operation: Show inputs: Show intersections:

Polygon A area: --

Polygon B area: --

Result area: --

Intersections: --

Try this:

Intersection: Purple area where polygons overlap (A AND B)
Union: Yellow area covered by either polygon (A OR B)
Difference: Red area in A but not in B (A NOT B)
Show intersections: Red dots where edges cross
Hide inputs: See only the result polygon
Notice: Area(A ∩ B) + Area(A \ B) + Area(B \ A) = Area(A ∪ B)

Key insight: Overlay operations are set operations on continuous space—the foundation of “What areas meet multiple criteria?”

6. Interpretation

Multi-Criteria Site Selection

Problem: Find suitable locations for solar farm:

Must be: flat land (slope < 5°)
Must be: within 2km of transmission lines
Must NOT be: protected areas or wetlands

Solution using overlay:

suitable_slope = reclassify(DEM, slope < 5°)
near_power = buffer(transmission_lines, 2000m)
buildable = suitable_slope ∩ near_power
final = buildable \ (protected ∪ wetlands)

Each step is a polygon operation.

Zoning Analysis

Question: How much residential land is in the 100-year floodplain?

residential = parcels WHERE zone = 'R1'
at_risk = residential ∩ floodplain_100yr
area_at_risk = sum(area(at_risk))

Result: Quantifies flood exposure for land use planning.

Habitat Fragmentation

Measure connectivity: Find contiguous forest patches.

forest = land_cover WHERE type = 'forest'
continuous = union(forest)  # Merge touching polygons
patches = count_components(continuous)

Fragmentation index: More patches = more fragmented = lower wildlife connectivity.

7. What Could Go Wrong?

Degenerate Cases

Touching polygons (shared edge, no overlap):

Intersection = line segment (zero area) or empty

Expected: Empty polygon
Reality: May return degenerate polygon (all vertices collinear)

Solution: Check result area > threshold, discard if zero/tiny.

Touching at single vertex:

Similarly produces degenerate result.

Numerical Precision

Floating-point arithmetic causes issues:

Intersection point calculated as (5.0000000001, 3.0)
Expected: (5.0, 3.0)

Result: Duplicate vertices, tiny slivers, self-intersecting polygons

Solution:

Round coordinates to tolerance (e.g., 6 decimal places)
Snap vertices within threshold
Use robust predicates (exact arithmetic for orientation tests)

Sliver Polygons

Very thin polygons from near-parallel edges:

Edge of A at y = 10.00001
Edge of B at y = 10.00000

Intersection: Polygon with width 0.00001 units

Problem: Inflates vertex count, causes numerical instability, visually ugly

Solution: Remove slivers below area threshold.

Multiple Components

Union of non-overlapping polygons:

Result should be two separate polygons, not one.

Simple implementation: Returns single polygon with disconnected components (invalid).

Proper handling: Return MultiPolygon (collection of polygons).

8. Extension: Boolean Operations on MultiPolygons

Real datasets have multiple polygons:

All protected areas = collection of many parks/preserves.

MultiPolygon: Set of disjoint polygons treated as single feature.

Overlay operations:

\[\text{MultiPoly}_1 \cap \text{MultiPoly}_2 = \bigcup_{i,j} (P_{1i} \cap P_{2j})\]

Algorithm:

For each polygon in MultiPolygon1:
For each polygon in MultiPolygon2:
Compute pairwise intersection
Collect all non-empty results

Union similar: Collect all polygons, merge overlapping ones.

Complexity: $O(nm)$ where $n$, $m$ are polygon counts.

Optimization: Spatial index (R-tree) to skip non-overlapping pairs.

9. Math Refresher: Set Theory and Boolean Algebra

Set Operations

Intersection (AND):

\[A \cap B = \{x : x \in A \text{ AND } x \in B\}\]

Properties:

Commutative: $A \cap B = B \cap A$
Associative: $(A \cap B) \cap C = A \cap (B \cap C)$
Identity: $A \cap U = A$ (where $U$ is universal set)

Union (OR):

\[A \cup B = \{x : x \in A \text{ OR } x \in B\}\]

Properties:

Commutative: $A \cup B = B \cup A$
Associative: $(A \cup B) \cup C = A \cup (B \cup C)$
Identity: $A \cup \emptyset = A$

Difference (NOT):

\[A \setminus B = \{x : x \in A \text{ AND } x \notin B\}\]

NOT commutative: $A \setminus B \neq B \setminus A$ (generally)

Symmetric Difference (XOR):

\[A \triangle B = (A \setminus B) \cup (B \setminus A)\]

Equivalent: $A \triangle B = (A \cup B) \setminus (A \cap B)$

De Morgan’s Laws

\[\overline{A \cup B} = \overline{A} \cap \overline{B}\] \[\overline{A \cap B} = \overline{A} \cup \overline{B}\]

Application: $A \setminus B = A \cap \overline{B}$

Spatial meaning: Difference is intersection with complement.

Summary

Overlay operations combine spatial datasets using set operations
Intersection (∩): Areas in both polygons (AND)
Union (∪): Areas in either polygon (OR)
Difference (): Areas in first but not second (NOT)
Line segment intersection detects where polygon edges cross
Weiler-Atherton algorithm traces polygon boundaries to compute overlay results
Applications: Multi-criteria site selection, zoning analysis, habitat assessment
Challenges: Numerical precision, degenerate cases, sliver polygons, multiple components
Robust implementation: Use computational geometry libraries (GEOS, Shapely, JTS)
Set theory foundation: Boolean algebra on continuous 2D space
