Map Algebra and Focal Operations

How do you add two rasters? Smooth noisy elevation data? Calculate slope from a DEM? Map algebra defines mathematical operations on rasters—local (cell-by-cell), focal (neighborhood), zonal (by region), and global. This model derives convolution, implements common kernels, and shows how raster math powers spatial analysis.

Prerequisites: matrix operations, convolution, weighted averaging, kernel operations

27 Feb 2026 Updated 12 Mar 2026 14 min read

1. The Question

How do you find suitable land that is both flat AND near water?

Map algebra treats rasters as mathematical objects that can be added, multiplied, and combined with logical operations:

Examples:

Suitability modelling: Combine slope, distance, and land cover grids
Change detection: Subtract two dates: change = image2 - image1
NDVI calculation: (NIR - Red) / (NIR + Red) (from Model 25)
Terrain smoothing: Average each cell with its neighbors
Slope calculation: Gradient from elevation differences

The mathematical question: What operations can we perform on raster grids, and how do we implement neighborhood analysis efficiently?

2. The Conceptual Model

Four Classes of Map Algebra

1. Local Operations (Cell-by-Cell)

Output value depends only on value(s) at same position in input(s).

\[z_{\text{out}}[i,j] = f(z_1[i,j], z_2[i,j], \ldots)\]

Examples:

Add: elevation_change = dem_2020 - dem_2010
Multiply: suitable = slope_ok * soil_ok * zoning_ok
Reclassify: if z > 100 then 1 else 0

2. Focal Operations (Neighborhood)

Output depends on value and its neighbors (moving window).

\[z_{\text{out}}[i,j] = f(z[i-k:i+k, j-k:j+k])\]

Examples:

Mean filter: Average 3×3 neighborhood
Gaussian blur: Weighted average
Edge detection: Gradient computation

3. Zonal Operations (Regional)

Output depends on all cells in a zone (region).

\[z_{\text{out}}[i,j] = f(\{z[m,n] : \text{zone}[m,n] = \text{zone}[i,j]\})\]

Examples:

Mean elevation per watershed
Total area per land cover class
Maximum temperature per county

4. Global Operations (Entire Raster)

Output depends on all cells.

\[z_{\text{out}}[i,j] = f(\text{all } z[m,n])\]

Examples:

Euclidean distance transform
Cost-distance analysis
Viewshed computation

3. Building the Mathematical Model

Local Operations

Unary (single input):

\[z_{\text{out}}[i,j] = f(z_{\text{in}}[i,j])\]

Examples:

Square root: $\sqrt{z}$
Threshold: $z > 100$
Reclassify: Map values to classes

Binary (two inputs):

\[z_{\text{out}}[i,j] = f(z_1[i,j], z_2[i,j])\]

Examples:

Sum: $z_1 + z_2$
Difference: $z_1 - z_2$
Ratio: $z_1 / z_2$
Logical AND: $z_1 \land z_2$

Multi-input:

\[z_{\text{out}}[i,j] = f(z_1[i,j], z_2[i,j], \ldots, z_n[i,j])\]

Example - Weighted sum:

\[z = w_1 z_1 + w_2 z_2 + \cdots + w_n z_n\]

Where $\sum w_i = 1$ (weights sum to 1).

Focal Operations: Convolution

Kernel (filter): Small matrix of weights $K$ (typically 3×3, 5×5, or 7×7).

Convolution:

\[z_{\text{out}}[i,j] = \sum_{m=-k}^{k} \sum_{n=-k}^{k} z[i+m, j+n] \cdot K[m,n]\]

Where kernel size is $(2k+1) \times (2k+1)$.

Example - 3×3 mean filter:

\[K = \frac{1}{9}\begin{bmatrix} 1 & 1 & 1 \\ 1 & 1 & 1 \\ 1 & 1 & 1 \end{bmatrix}\]

Each output cell = weighted average of input cell and its 8 neighbors.

Properties:

Linear: Convolution is a linear operation
Translation invariant: Same operation everywhere
Separable: Some kernels can be split into 1D operations (faster)

Common Kernels

1. Box Filter (Mean)

\[K_{\text{box}} = \frac{1}{9}\begin{bmatrix} 1 & 1 & 1 \\ 1 & 1 & 1 \\ 1 & 1 & 1 \end{bmatrix}\]

Effect: Smooths image, reduces noise, blurs edges.

2. Gaussian Filter

\[K_{\text{gauss}} = \frac{1}{16}\begin{bmatrix} 1 & 2 & 1 \\ 2 & 4 & 2 \\ 1 & 2 & 1 \end{bmatrix}\]

Effect: Smooth but preserves edges better than box filter.

Formula: $K[m,n] = \frac{1}{2\pi\sigma^2} e^{-(m^2+n^2)/(2\sigma^2)}$

3. Sobel Filter (Edge Detection)

Horizontal edges:

\[K_x = \begin{bmatrix} -1 & 0 & 1 \\ -2 & 0 & 2 \\ -1 & 0 & 1 \end{bmatrix}\]

Vertical edges:

\[K_y = \begin{bmatrix} -1 & -2 & -1 \\ 0 & 0 & 0 \\ 1 & 2 & 1 \end{bmatrix}\]

Gradient magnitude:

\[|\nabla z| = \sqrt{(K_x * z)^2 + (K_y * z)^2}\]

4. Laplacian (Second Derivative)

\[K_{\text{laplacian}} = \begin{bmatrix} 0 & 1 & 0 \\ 1 & -4 & 1 \\ 0 & 1 & 0 \end{bmatrix}\]

Effect: Detects regions of rapid intensity change.

Edge Handling

Problem: Kernel extends beyond raster boundary at edges.

Strategies:

Ignore (NoData): Output is NoData at edges
Reflect: Mirror pixel values across boundary
Wrap: Treat as toroidal (opposite edges connect)
Constant: Assume fixed value (often 0) beyond edge
Extend: Replicate edge pixel values

Most common: Reflect or constant padding.

4. Worked Example by Hand

Problem: Apply 3×3 mean filter to this elevation grid.

Input (meters):

    j=0  j=1  j=2  j=3
i=0  10   12   14   16
i=1  11   13   15   17
i=2  12   14   16   18
i=3  13   15   17   19

Calculate output at position [1,1].

Solution

Kernel (mean filter):

\[K = \frac{1}{9}\begin{bmatrix} 1 & 1 & 1 \\ 1 & 1 & 1 \\ 1 & 1 & 1 \end{bmatrix}\]

Position [1,1] neighborhood:

12  14
13  15
14  16

Convolution:

\[z_{\text{out}}[1,1] = \frac{1}{9}(10 + 12 + 14 + 11 + 13 + 15 + 12 + 14 + 16)\] \[= \frac{1}{9}(117) = 13.0 \text{ m}\]

Verification: Central value is 13, neighbors average to 13, so mean is 13 ✓

Position [1,2] (next to the right):

Neighborhood:

14  16
15  17
16  18

\[z_{\text{out}}[1,2] = \frac{1}{9}(12 + 14 + 16 + 13 + 15 + 17 + 14 + 16 + 18)\] \[= \frac{1}{9}(135) = 15.0 \text{ m}\]

Notice: Smooth gradient preserved (values increase uniformly → mean filter doesn’t change them much).

5. Computational Implementation

Below is an interactive map algebra demonstration.

Operation type: Focal kernel: Show kernel weights:

Try this:

Mean filter: Smooths the noisy gradient pattern
Gaussian: Smoother than mean, better edge preservation
Sobel: Highlights edges (bright = steep gradient)
Laplacian: Detects rapid changes (edges appear as white/black pairs)
Local operations: Try different combinations of inputs
Show kernel: See the actual weight matrices

Key insight: Convolution is just weighted averaging—different kernels extract different spatial features.

6. Interpretation

Suitability modelling

Problem: Find land suitable for solar farm.

Criteria:

Slope < 5° (flat land)
Within 2km of roads
Not in protected areas
South-facing aspect

Map algebra solution:

slope_ok = (slope < 5)              # Binary: 1 if true, 0 if false
road_ok = (road_distance < 2000)    # Within 2km
protected_ok = (protected == 0)     # Not protected (0 = no)
aspect_ok = (aspect > 135) AND (aspect < 225)  # South-facing

suitable = slope_ok * road_ok * protected_ok * aspect_ok

Result: Raster where 1 = suitable, 0 = not suitable.

Count suitable cells:

suitable_area = sum(suitable) * cell_area

Terrain Analysis

Slope from DEM using focal operations:

Finite difference approximation:

\[\frac{\partial z}{\partial x} \approx \frac{z[i,j+1] - z[i,j-1]}{2\Delta x}\] \[\frac{\partial z}{\partial y} \approx \frac{z[i+1,j] - z[i-1,j]}{2\Delta y}\]

Slope angle:

\[\text{slope} = \arctan\sqrt{\left(\frac{\partial z}{\partial x}\right)^2 + \left(\frac{\partial z}{\partial y}\right)^2}\]

This is Sobel-like kernel operation!

Change Detection

Detect forest loss from NDVI time series:

ndvi_2010 = (nir_2010 - red_2010) / (nir_2010 + red_2010)
ndvi_2020 = (nir_2020 - red_2020) / (nir_2020 + red_2020)

change = ndvi_2020 - ndvi_2010

# Forest loss where NDVI decreased significantly
forest_loss = (change < -0.2) AND (ndvi_2010 > 0.6)

Image Enhancement

Contrast stretch (local operation):

min_val = global_minimum(image)
max_val = global_maximum(image)

stretched = 255 * (image - min_val) / (max_val - min_val)

Unsharp masking (focal operation):

blurred = gaussian_filter(image)
edges = image - blurred
enhanced = image + alpha * edges

Where $\alpha$ controls enhancement strength.

7. What Could Go Wrong?

Division by Zero

NDVI calculation:

ndvi = (nir - red) / (nir + red)

Problem: If NIR + Red = 0, division by zero.

Solution: Mask or set NoData where denominator ≈ 0:

denominator = nir + red
ndvi = WHERE(denominator > epsilon, (nir - red) / denominator, NoData)

Type Overflow

Multiplying large integers:

area = count * cell_size  # If count and cell_size are int32

Problem: Result may exceed int32 range (2.1 billion).

Solution: Cast to float or int64 before operation.

Edge Artifacts

Kernels create NoData ring around edge.

3×3 kernel: 1-pixel ring
5×5 kernel: 2-pixel ring

Problem: Successive operations shrink valid area.

Solution: Pad raster before operation, crop after.

Inappropriate Kernel for Data

Mean filter on categorical data:

land_cover = [1, 1, 2, 2]  # 1=forest, 2=urban
mean = (1 + 1 + 2 + 2) / 4 = 1.5

Problem: Class 1.5 doesn’t exist!

Solution: Use modal filter (most common value) for categorical data.

8. Extension: Separable Filters

Many 2D filters can be decomposed into 1D operations.

Example - 2D Gaussian:

\[G_{2D}(x, y) = \frac{1}{2\pi\sigma^2} e^{-(x^2+y^2)/(2\sigma^2)}\]

Separable:

\[G_{2D}(x, y) = G_{1D}(x) \times G_{1D}(y)\]

Where:

\[G_{1D}(x) = \frac{1}{\sqrt{2\pi}\sigma} e^{-x^2/(2\sigma^2)}\]

Computational advantage:

2D convolution: $O(n^2 \times k^2)$ where $k$ = kernel size
Separable (two 1D): $O(n^2 \times 2k)$

For 5×5 kernel:

2D: 25 multiplications per pixel
Separable: 10 multiplications per pixel
2.5× speedup

Implementation:

# Instead of one 2D convolution:
result = convolve_2d(image, kernel_2d)

# Do two 1D convolutions:
temp = convolve_1d(image, kernel_x, axis=0)  # Rows
result = convolve_1d(temp, kernel_y, axis=1)  # Columns

9. Math Refresher: Convolution

1D Convolution

Signal: $f[n]$
Kernel: $g[m]$

Convolution:

\[(f * g)[n] = \sum_{m=-\infty}^{\infty} f[m] \cdot g[n-m]\]

Interpretation: Flip kernel, slide across signal, multiply and sum.

Example:

f = [1, 2, 3, 4, 5]
g = [0.25, 0.5, 0.25]  # Simple smoothing

(f * g)[2] = 0.25*f[1] + 0.5*f[2] + 0.25*f[3]
           = 0.25*2 + 0.5*3 + 0.25*4
           = 0.5 + 1.5 + 1.0 = 3.0

2D Convolution

Image: $I[i,j]$
Kernel: $K[m,n]$

Convolution:

\[(I * K)[i,j] = \sum_m \sum_n I[i-m, j-n] \cdot K[m,n]\]

For 3×3 kernel centered at origin:

\[= K[-1,-1]I[i+1,j+1] + K[0,-1]I[i,j+1] + \cdots + K[1,1]I[i-1,j-1]\]

Note: Kernel is flipped. For symmetric kernels (most common), flipping has no effect.

Properties

Commutativity: $f * g = g * f$
Associativity: $(f * g) * h = f * (g * h)$
Distributivity: $f * (g + h) = f * g + f * h$
Identity: $f * \delta = f$ (where $\delta$ is impulse: 1 at origin, 0 elsewhere)

Summary

Map algebra defines mathematical operations on rasters
Four types: Local (cell-by-cell), Focal (neighborhood), Zonal (regional), Global (entire raster)
Local operations: Arithmetic, logical, reclassification—independent cells
Focal operations: Convolution with kernels—neighborhood analysis
Common kernels: Mean (smooth), Gaussian (better smooth), Sobel (edges), Laplacian (change)
Convolution = weighted sum of neighbors using kernel weights
Applications: Suitability modelling, terrain analysis, change detection, image enhancement
Challenges: Division by zero, type overflow, edge artifacts, inappropriate kernels
Optimization: Separable filters reduce computation 2-3×
Map algebra enables complex spatial analysis from simple operations
